Frame
C:62 Monocoque Advanced Twin Mold Technology, Aluminum 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, Full Integrated Battery
Fork
RockShox 35 Silver, Tapered, 15x110mm, eMTB Approved, 140mm
Shock
RockShox Deluxe Select+, 185x55mm, Rebound Adjust, Trunnion Mount, Lockout
Shock hardware
Top: 54mm Trunnion Mount, Bottom: 22.2x8mm
Headset
27.5: ACROS AZX-1032, BlockLock 120°, Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm) // 29: ACROS AZX-1030, Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm)
Stem
CUBE Performance Stem E-MTB, 31.8mm
Handlebar
Newmen Evolution SL 318.25, 760mm
Grips
Natural Fit MTB Performance Lock On
Rear derailleur
Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed
Chain guide
e*thirteen Plus e*spec
Shifters
Shimano Deore SL-M6100, Rapidfire-Plus
Brake system
Shimano BR-MT520, Hydr. Disc Brake (203/203)
Crankset
ACID E-Crank, 165mm (27.5: 36T // 29: 34T)
Crankset chainring sizes
27.5: 36T // 29: 34T
Cassette
Shimano Deore CS-M6100, 10-51T
Number of gears
12
Chain
Shimano CN-M6100
Rims
CUBE EX30, 32H, Disc, Tubeless Ready
Front hub
Shimano HB-MT400-B, 15mm, Boost, Centerlock
Rear hub
Shimano FH-MT410-B, 12mm, Boost, Centerlock
Tires
Schwalbe Nobby Nic, PerfL, 2.6
Saddle
Natural Fit Venec
Seat post
CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm (XS, S: 100mm, M: 125mm, L, XL: 150mm)
Seat post clamp
CUBE Screwlock Semi Integrated, 34.9mm
Engine
Bosch Drive Unit Performance CX Generation 4 (85Nm) Cruise (250Watt)
Battery
Bosch PowerTube 625
Charger
Bosch 2A
Display
Bosch Kiox
As with any product, specification is subject to change without prior notification. You are advised to confirm current specification before buying. Please note that this bike does not come with pedals.
