The Merida Scultura Endurance 4000 is a carbon road bike engineered for tarmac adventures and long-distance comfort.
The Merida Scultura Endurance 4000 is a carbon road bike engineered for tarmac adventures and long-distance comfort.
Merida

2025 Merida Scultura Endurance 4000 Road Bike - Silk Blue/Black

Pre-Order

With Pre-Order, you can purchase the latest items added to our store in advance of them arriving with us.

Your Pre-Order is prioritised (at no additional charge); meaning that as soon as the product arrives with us, we can wrap it straight back up; ready for collection via Click & Collect or despatch to you — it often never even hits the stock room shelves!

Pre-Launch

With Pre-Launch, the date when we expect to receive the product ourselves is still a little too hazy to be confident in accepting Pre-Orders.

So, instead, you can submit your email address against the item you are interested in and we will email you as soon as stock arrives on the system.

Estimated Delivery & Collection Dates

Estimated Delivery & Collection Dates are given on Pre-Order and Pre-Launch products. They are for indication purposes only and can change at any time without notice.

The dates we provide are based on indications given by our suppliers. Whenever we get updated information from our suppliers we will endeavour to update the Estimated Delivery & Collection Dates provided on product pages.

We estimate this will be ready for despatch to you or collection via Click & Collect on Undetermined

2025 Merida Scultura Endurance 4000 Road Bike - Silk Blue/Black

Season:2025

Brand:Merida

Code:P-Q375

The Merida Scultura Endurance 4000 is a carbon road bike engineered for tarmac adventures and long-distance comfort. With advanced components and a geometry focused on confidence and stability, this bike is perfect for cyclists who want to enjoy extended hours on the saddle without compromising performance.

  • Comfort-Driven Geometry: Designed for an upright and relaxed riding position, ideal for endurance cycling.
  • Lightweight Carbon Frame and Fork: Combines stiffness, comfort, and efficiency for an exceptional ride quality.
  • Shimano 105 2x12 Groupset: Reliable, smooth shifting with a compact chainset for varied terrains.
  • Shimano 105 Hydraulic Disc Brakes: Powerful and consistent braking in all weather conditions.
  • Carbon Seat Post: Enhances comfort by absorbing road vibrations.
  • Maxxis Re-Fuse 32c Tyres: Durable and grippy, perfect for tarmac and rougher country roads.

Advanced Endurance Design

The Scultura Endurance series bridges the gap between Merida’s Silex and Scultura models, delivering a bike that’s tailor-made for long-distance tarmac rides. The modern frame design includes a longer head tube for an upright position, a slacker head tube angle, and an extended wheelbase for superior stability at speed.

Unmatched Comfort and Capability

  • Generous Tyre Clearance: Fits up to 35c tyres (32c with mudguards) for increased comfort and reduced rolling resistance on uneven surfaces.
  • Neat Cable Integration: Internal cable routing through the headset creates a clutter-free cockpit.
  • Customisable Setup: Includes a hidden seat clamp and a removable rear seat stay bridge for mudguard compatibility.

Reliable Performance in All Conditions

Equipped with Shimano 105 hydraulic disc brakes, the Scultura Endurance 4000 provides confident stopping power. The flat-mount calipers are paired with CNC’d aluminium Disc Cooler fins, reducing heat by up to 35% for consistent performance even on steep descents.

Why Choose the Merida Scultura Endurance 4000

This carbon endurance road bike offers exceptional value, combining a high-performance Shimano 105 groupset with hydraulic disc brakes and a lightweight carbon frame. It’s designed for riders who prioritise comfort, stability, and efficiency for long rides on tarmac or uneven roads.

Experience the perfect blend of comfort and performance with the Merida Scultura Endurance 4000 Road Bike.

Technical Information
  • FRAME
    CF3 carbon, Nano Matrix for impact resistance. Internal cable routing, 142 x12mm axle standard, BB86 BB standard, flat mount rear brake with Disc Cooler, 1 1/2" headtube. Fully integrated seat clamp. Max tyre size 700 x 35c (700 x 32c with mudguard)
  • FORK
    Scultura Endurance CF3 Disc; full carbon, tapered steerer. Disc Cooler; Max tyre size: 700 x 35c (700 x 32c with mudguard)
  • GEARS
    24
  • SHIFTERS
    Shimano 105 disc
  • FRONT DERAILLEUR
    Shimano 105
  • REAR DERAILLEUR
    Shimano 105; GS
  • BOTTOM BRACKET
    SM-BB71-41B, Pressfit 86.5
  • CHAIN
    Shimano CN-M6100-12
  • CHAINSET
    Shimano 105; FCR7100, 50-34 tooth chainset; Crank length - 165mm (XXS), 170mm (XS), 172.5mm (S/M/L), 175mm (XL)
  • CASSETTE
    Shimano CS-R7101; 11-34 teeth; 12 speed
  • BRAKE LEVER
    Shimano 105
  • FRONT BRAKE
    Shimano 105; Hydraulic disc brake caliper with Shimano RT54; 160mm rotor
  • REAR BRAKE
    Shimano 105; Hydraulic disc brake caliper with Shimano RT54; 160mm rotor
  • GRIPS
    Merida Expert
  • HANDLEBAR
    Merida Expert SLII; aluminium; 380mm (XXS-XS-S), 400mm (M-L), 420mm (XL)
  • STEM
    Merida Expert SL 2PII; aluminium; -9 degree rise - Length- 90mm (XXS-XS-S), 100mm (M), 110mm (L/XL)
  • HEADSET
    Merida Team SL (SE-301 neck)
  • SADDLE
    Merida Comp SL; V-mount - made with 25% recycled material
  • SEATPOST
    Merida Expert CC; 27.2mm diameter; 15mm layback; Carbon
  • WHEEL SIZE
    700c
  • RIMS
    Merida Expert SLII; 23mm inner rim width; 25mm rim depth; aluminium; Tubeless ready (tubeless tape and valves not included)
  • SPOKES
    Double Butted Black stainless
  • FRONT HUB
    Shimano HB-TC500; 100 x 12mm; 28 spoke; Centerlock
  • REAR HUB
    Shimano FH-TC500-HL; 142 x 12mm; 28 spoke; Centerlock
  • FRONT TYRE
    Maxxis RE-FUSE; 700 x 32C; Kevlar bead
  • REAR TYRE
    Maxxis RE-FUSE; 700 x 32C; Kevlar bead
As with any product, specification is subject to change without prior notification. You are advised to confirm current specification before buying. Please note that this bike does not come with pedals.
Sizing Information

SIZING

Size in ft4'11" - 5'2"5'3" - 5'5"5'5" - 5'8"5'9" - 5'11"6'0" - 6'2"6'3" - 6'7"
Size in cm150 - 158cm159 - 165cm166 - 173cm174- 182cm183 - 189cm190 - 200cm
Bike SizeXXSXSSMLXL

GEOMETRY

CF3XSSMLXL
Seat Tube470mm490mm510mm530mm560mm
Top Tube Horizontal524mm538mm553mm568mm583mm
Head Tube Length152mm161mm177mm197mm222mm
Head Tube Angle71°72°73°73°73.5°
Head Tube Angle74°74°73.5°73.5°73.5°
Chain Stays418mm418mm418mm418mm418mm
Bottom Bracket Drop66mm66mm66mm66mm66mm
Fork Length380mm380mm380mm380mm380mm
Standover Height767mm785mm803mm823mm852mm
Stack552mm565mm584mm603mm629mm
Reach366mm376mm380mm389mm397mm
Wheelbase997mm1001mm1001mm1017mm1026mm
