Designed for long rides on tarmac, this bike is perfect for cyclists seeking stability, confidence, and speed over extended distances.
Designed for long rides on tarmac, this bike is perfect for cyclists seeking stability, confidence, and speed over extended distances.
Merida

2025 Merida Scultura Endurance 9000 Road Bike - Purple/Blue - Size Medium

Pre-Order

With Pre-Order, you can purchase the latest items added to our store in advance of them arriving with us.

Your Pre-Order is prioritised (at no additional charge); meaning that as soon as the product arrives with us, we can wrap it straight back up; ready for collection via Click & Collect or despatch to you — it often never even hits the stock room shelves!

Pre-Launch

With Pre-Launch, the date when we expect to receive the product ourselves is still a little too hazy to be confident in accepting Pre-Orders.

So, instead, you can submit your email address against the item you are interested in and we will email you as soon as stock arrives on the system.

Estimated Delivery & Collection Dates

Estimated Delivery & Collection Dates are given on Pre-Order and Pre-Launch products. They are for indication purposes only and can change at any time without notice.

The dates we provide are based on indications given by our suppliers. Whenever we get updated information from our suppliers we will endeavour to update the Estimated Delivery & Collection Dates provided on product pages.

We estimate this will be ready for despatch to you or collection via Click & Collect on Undetermined

2025 Merida Scultura Endurance 9000 Road Bike - Purple/Blue - Size Medium

Season:2025

Brand:Merida

Code:P-Q170

The Merida Scultura Endurance 9000 is the pinnacle of endurance road cycling, delivering an unmatched combination of performance, comfort, and innovation. Designed for long rides on tarmac, this bike is perfect for cyclists seeking stability, confidence, and speed over extended distances.

  • Comfort-Focused Geometry: Optimised for long hours in the saddle with an upright and relaxed riding position.
  • Lightweight Carbon Frame and Fork: Delivers exceptional performance, comfort, and stiffness.
  • Shimano Ultegra Di2 2x12 Groupset: Precision electronic shifting for seamless gear changes.
  • Reynolds ATR Carbon Wheelset: Tubeless-ready, paired with 32c Continental GP5000 All-Season Tyres for enhanced grip and durability.
  • Integrated Carbon Cockpit: Sleek, clutter-free design with hidden cable routing.
  • Carbon S-Flex Seat Post: Adds compliance for a smoother ride experience.
  • Hydraulic Disc Brakes with Cooling Technology: Flat-mount calipers and Disc Cooler fins reduce operating temperatures by up to 35% for consistent stopping power.

Built for Endurance and Adventure

Sitting between the Silex and Scultura in the Merida lineup, the Scultura Endurance is crafted for tarmac adventures. Its modern frame design includes a longer head tube for a more upright position, a slacker head tube angle, and an extended wheelbase for unparalleled stability at high speeds. With 12mm bolt-through axles and a full carbon tapered fork, you get enhanced frame stiffness and precise steering.

Superior Comfort and Versatility

  • Tyre Clearance: Accommodates up to 35c tyres (32c with mudguards) for lower pressure and increased comfort on rough roads.
  • Neat Finishing Touches: Hidden seat clamps, internal cable routing through the headset, and a removable seat stay bridge for mudguard mounting keep the bike sleek and functional.

Confidence in All Conditions

All Scultura Endurance models are equipped with powerful hydraulic disc brakes, ensuring reliable stopping power in any weather. Flat-mount calipers and Merida’s CNC’d aluminium Disc Cooler technology enhance performance and keep temperatures under control for optimal braking efficiency.

Why Choose the Merida Scultura Endurance 9000

This top-tier endurance road bike is designed to excel on any tarmac adventure. From the carbon frame to the Shimano Ultegra Di2 electronic drivetrain and Reynolds carbon wheelset, every component reflects a commitment to quality and performance.

Discover the Merida Scultura Endurance 9000, where comfort meets capability on the open road.

Technical Information
  • FRAME
    CF3 carbon, Nano Matrix for impact resistance. Internal cable routing, 142 x12mm axle standard, BB86 BB standard, flat mount rear brake with Disc Cooler, 1 1/2" headtube. Fully integrated seat clamp. Max tyre size 700 x 35c (700 x 32c with mudguard)
  • FORK
    Scultura Endurance CF3 Disc; full carbon, tapered steerer. Disc Cooler; Max tyre size: 700 x 35c (700 x 32c with mudguard)
  • GEARS
    24
  • SHIFTERS
    Shimano Ultegra Di2
  • FRONT DERAILLEUR
    Shimano Ultegra Di2; FD-R8150
  • REAR DERAILLEUR
    Shimano Ultegra Di2; FD-R8150
  • BOTTOM BRACKET
    SM-BB72-41B, Pressfit 86.5
  • CHAIN
    Shimano CN-M8100-12
  • CHAINSET
    Shimano Ultegra; 50-34 tooth chainset; Crank length - 165mm (XXS), 170mm (XS), 172.5mm (S/M/L), 175mm (XL)
  • CASSETTE
    Shimano CS-R8101; 11-34 teeth; 12 speed
  • BRAKE LEVER
    Shimano Ultegra
  • FRONT BRAKE
    Shimano Ultegra; Hydraulic disc brake caliper with Shimano CL800; 160mm rotor
  • REAR BRAKE
    Shimano Ultegra; Hydraulic disc brake caliper with Shimano CL800; 160mm rotor
  • GRIPS
    Merida Expert
  • HANDLEBAR
    Team SL 1P Integrated; carbon; 380mm (XXS-XS-S), 400mm (M-L), 420mm (XL)
  • STEM
    Team One-Piece Integrated; carbon - Length - 90mm (XXS-XS-S), 100mm (M), 110mm (L-XL)
  • HEADSET
    Merida Team SL (SE-301 neck)
  • SADDLE
    Scratch M5 with V-mount adapter; includes Merida minitool
  • SEATPOST
    Merida Team SL; 27.2mm diameter; 15mm layback; Carbon; S-Flex
  • WHEEL SIZE
    700c
  • RIMS
    Part of wheelset - Reynolds ATR DB, 23mm inner rim width; 40mm rim depth; carbon; Tubeless ready (tubeless tape and valves included)
  • SPOKES
    Part of wheelset
  • FRONT HUB
    Part of wheelset - Reynolds ATR DB, 100 x 12mm; Centerlock
  • REAR HUB
    Part of wheelset - Reynolds ATR DB, 142 x 12mm; Centerlock
  • FRONT TYRE
    Continental GP5000 AllSeason TR; 700 x 32C; Kevlar bead
  • REAR TYRE
    Continental GP5000 AllSeason TR; 700 x 32C; Kevlar bead
As with any product, specification is subject to change without prior notification. You are advised to confirm current specification before buying. Please note that this bike does not come with pedals.
Sizing Information

SIZING

Size in ft4'11" - 5'2"5'3" - 5'5"5'5" - 5'8"5'9" - 5'11"6'0" - 6'2"6'3" - 6'7"
Size in cm150 - 158cm159 - 165cm166 - 173cm174- 182cm183 - 189cm190 - 200cm
Bike SizeXXSXSSMLXL

GEOMETRY

CF3XSSMLXL
Seat Tube470mm490mm510mm530mm560mm
Top Tube Horizontal524mm538mm553mm568mm583mm
Head Tube Length152mm161mm177mm197mm222mm
Head Tube Angle71°72°73°73°73.5°
Head Tube Angle74°74°73.5°73.5°73.5°
Chain Stays418mm418mm418mm418mm418mm
Bottom Bracket Drop66mm66mm66mm66mm66mm
Fork Length380mm380mm380mm380mm380mm
Standover Height767mm785mm803mm823mm852mm
Stack552mm565mm584mm603mm629mm
Reach366mm376mm380mm389mm397mm
Wheelbase997mm1001mm1001mm1017mm1026mm
