frame
FACT 11m carbon chassis and rear-end, asymmetrical design, 29 Trail Geometry, SWAT™ Door integration, head tube angle adjustment, horst pivot BB adjustment, threaded BB, fully enclosed internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 150mm of travel
SWAT
Increased-volume SWAT™ Door integration with 22oz SWAT™ Bladder
rear shock
FOX FLOAT X Performance Elite, Rx Trail Tune, EVOL Air sleeve, 2-position lever w/ LSC adjustment, S1:210x50mm, S2-S6:210x55mm
fork
FOX FLOAT 36 Performance Elite, GRIP2 damper, 15x110mm, 44mm offset, S1: 150mm of travel, S2-S6: 160mm of travel
stem
Alloy Trail Stem, 35mm bar bore
handlebars
Specialized Trail, 7050 alloy, 8-degree backsweep, 6-degree upsweep, 30mm rise, 800mm, 35mm clamp
grips
Deity Grips
saddle
Bridge Comp, Hollow Cr-mo rails, 155/143mm
seatpost
OneUp, Dropper Post-V2, MMX lever, 34.9 (S1:120mm, S2/S3:150mm, S4: 180mm, S5/S6: 210mm)
front brake
SRAM Code RS, 4-piston caliper, hydraulic disc, 200mm Centerline
rear brake
SRAM Code RS, 4-piston caliper, hydraulic disc, 200mm Centerline
rear derailleur
SRAM GX Eagle AXS, w/ battery cover
shift levers
SRAM GX Eagle AXS Controller
cassette
Sram XG-1275, 12-speed, 10-52t
chain
SRAM GX Eagle, 12-speed
crankset
SRAM GX Eagle Alloy, DUB, 165/170/175mm, 32t
chainrings
32T
bottom bracket
SRAM DUB, BSA 73mm, Threaded
rims
Roval Traverse 29 Alloy, 30mm inner width, hand-built, 2Bliss Ready
front hub
Roval, sealed cartridge bearings, 15x110mm spacing, 28h
rear hub
Roval DT Swiss 370, Ratchet LN, SRAM XD driver body, 12mm thru-axle, 148mm spacing, 28h
spokes
DT Swiss Competition Race
front tyre
Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"
rear tyre
Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 29x2.3"
inner tubes
Standard, Presta valve
seat binder
Alloy, 38.6mm
As with any product, specification is subject to change without prior notification. You are advised to confirm current specification before buying. Please note that this bike does not come with pedals.
