The Stumpjumper Evo Alloy is not your normal trail bike.
The Stumpjumper Evo Alloy is not your normal trail bike.
Specialized

Ex-Demo: Specialized Stumpjumper Evo Elite Alloy FSR Mountain Bike - S4

£2,499.00 £4,399.00 43% off
Pre-Order

With Pre-Order, you can purchase the latest items added to our store in advance of them arriving with us.

Your Pre-Order is prioritised (at no additional charge); meaning that as soon as the product arrives with us, we can wrap it straight back up; ready for collection via Click & Collect or despatch to you — it often never even hits the stock room shelves!

Pre-Launch

With Pre-Launch, the date when we expect to receive the product ourselves is still a little too hazy to be confident in accepting Pre-Orders.

So, instead, you can submit your email address against the item you are interested in and we will email you as soon as stock arrives on the system.

Estimated Delivery & Collection Dates

Estimated Delivery & Collection Dates are given on Pre-Order and Pre-Launch products. They are for indication purposes only and can change at any time without notice.

The dates we provide are based on indications given by our suppliers. Whenever we get updated information from our suppliers we will endeavour to update the Estimated Delivery & Collection Dates provided on product pages.

We estimate this will be ready for despatch to you or collection via Click & Collect on Undetermined

Ex-Demo: Specialized Stumpjumper Evo Elite Alloy FSR Mountain Bike - S4

Season:2022

Brand:Specialized

Code:96322-4004 DEMO 1806T

Ex-Demo Bike: S4

Please contact 01752 849315 for details/images

As this is not a brand new bike, it may not feature the full original technical specification and is subject to change.

The Stumpjumper EVO Alloy isn't a normal trail bike as it's built to get gnarly, plain and simple. Featuring the same all-new design as the carbon model, including an adjustable head tube angle, 150mm of performance tuned travel, the adaptability of S-Sizing, and SWAT™ Door integration, in a lightweight yet tough M5 Alloy chassis, you're going to be able to bomb down trails that you thought you couldn't touch without a full-blown DH rig.

The Stumpjumper EVO Elite Alloy is built to brawl. With a bullet-proof SRAM GX Eagle 12-speed drivetrain, stout 30mm-wide alloy wheels, and Rx Tuned Fox FLOAT Factory suspension, there’s no trail too rowdy.

  • All the travel in the world is useless without the proper shock tuning and kinematics. For the new Stumpjumper EVO design, kinematic performance was prioritised. Applying lessons learnt while developing the Enduro, then following that with more than 1,000 hours of field and suspension lab development, Specialized have improved the pedaling performance of the Stumpjumper, and made it more capable, agile, and lively. Anti-squat has been increased, so the suspension better resists pedal bob, and bump performance was further improved on square-edge hits. This thing shreds trails, not legs.
  • The S-Sizing geometry of the new Stumpjumper EVO is Specialized's most progressive yet. Long, low, slack, short offset fork, steeper seat tube angle are requirements for modern progressive riding. Not everyone jibs the same way, which is why the geo on the new Stumpjumper EVO is fully adjustable with six different settings. You can adjust the BB height by 10mm, you can adjust your head angle by two-degrees, and you can make these adjustments independently of each other. If you want to go full-party mullet-mode, the EVO lets you run a 27.5-inch rear wheel mated with a 29-inch front.
  • Rider-First Engineered™ frames use a size-specific approach to ride characteristics that ensures benchmark handling and flawless performance, regardless of frame or rider size. Whether you’re a jump-happy grom riding an S1, or a DH-fiend giant in need of the lengthy S6, you’ll experience the same ride traits, including rail-sharp cornering and balanced front and rear stiffness at the lightest-possible weight.
  • Specialized introduced the SWAT™ door on the Stumpjumper in 2016, adding room in your frame for necessities like pumps and spare tubes, and immediately rendering jersey pockets redundant.
Technical Information
  • frame
    M5 Alloy chassis and rear-end, asymmetrical design, 29" Trail Geometry with S-Sizing, SWAT™ Door integration, head tube angle adjustment, horst pivot BB adjustment, threaded BB, fully enclosed internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 150mm of travel
  • SWAT
    SWAT™ Door integration
  • rear shock
    FOX FLOAT X Factory, Rx Trail Tune, EVOL Air sleeve, 2-position lever w/ LSC adjustment, S1:210x50mm, S2-S6:210x55mm
  • fork
    FOX FLOAT 36 Factory, GRIP2 damper, 15x110mm, 44mm offset, S1: 150mm of travel, S2-S6: 160mm of travel
  • stem
    Deity, 35.0mm
  • handlebars
    Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 30mm rise, 800mm width
  • tape
    Specialized Trail Grips
  • saddle
    Bridge Comp, Hollow Cr-mo rails, 155/143mm
  • seatpost
    OneUp, Dropper Post-V2, MMX lever, 34.9 (S1:120mm, S2/S3:150mm, S4: 180mm, S5/S6: 210mm)
  • front brake
    SRAM Code RS, 4-piston caliper, hydraulic disc, 200mm
  • rear brake
    SRAM Code RS, 4-piston caliper, hydraulic disc, 200mm
  • rear derailleur
    SRAM GX Eagle, 12-speed
  • shift levers
    SRAM GX Eagle, 12-speed
  • cassette
    SRAM XG-1275, 12-speed, 10-52t
  • chain
    SRAM GX Eagle, 12-speed
  • crankset
    SRAM GX Eagle, DUB, S1:165mm, S2-S5: 170mm, S6: 175mm
  • chainrings
    Alloy, 30T
  • bottom bracket
    SRAM DUB, BSA 73mm, threaded
  • rims
    Roval Traverse 29 Alloy, 30mm inner width, hand-built, 2Bliss Ready
  • front hub
    Roval, sealed cartridge bearings, 15x110mm spacing, 28h
  • rear hub
    Roval DT Swiss 370, Ratchet LN, SRAM XD driver body, 12mm thru-axle, 148mm spacing, 28h
  • spokes
    DT Swiss Competition Race
  • front tyre
    Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"
  • rear tyre
    Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 29x2.3"
  • inner tubes
    Standard, Presta valve
  • seat binder
    Alloy, 38.6mm
  • As with any product, specification is subject to change without prior notification. You are advised to confirm current specification before buying. Please note that this bike does not come with pedals.
Sizing Information
Size in ft4'11" - 5'3"5'2" - 5'8"5'5" - 5'11"5'8" - 6'2"5'10" - 6'4"6'2" - 6'8"
Size in cm150 - 160cm158 - 173cm165 - 180cm173 - 188cm178 - 193cm188 - 203cm
Equivalent to Bike SizeXSSMLXLXXL
Bike SizeS1S2S3S4S5S6

STUMPJUMPER, STUMPJUMPER EVO (STYLE SPECIFIC-SIZING) MY21 SIZING GUIDE

S-Sizing is based on what matters; rider size and style, not inseam. Six sizes, all with similar headtube lengths and standover allow you to choose the size that best suits your individual style. Smaller S-Size numbers are going to be more nimble, thanks to their shorter reach and front-centre measurement, while bigger S-Sizes deliver more stability and a roomier ride.

  • SIZE DOWN FOR MORE MANEUVERABILITY
  • SIZE UP FOR MORE STABILITY
