FRAME // FACT 9m carbon chassis / M5 Alloy rear triangle, 6Fattie/29 Trail Geometry, Integrated down tube battery, enclosed internal cable, Command Post IR routing, 148mm spacing, fully sealed cartridge bearings, 135mm of travel
FORK // RockShox Revelation RC 6Fattie/29, 51mm offset, 34mm stanchions, 150mm of travel
REAR SHOCK // RockShox Monarch RT, Rx Trail Tune, AUTOSAG, rebound and 2-position compression adjust, 197x48mm
FRONT HUB // Specialized, sealed cartridge bearings, 15x110mm spacing, 24h
REAR HUB // Specialized, sealed cartridge bearings, 12x148mm thru-axle, 28h
SPOKES // DT Swiss, stainless
RIMS // Roval Traverse 27.5, hookless alloy, 38mm inner width, tubeless ready, 24/28h
INNER TUBES // 27.5 x 2.3" / 3.0", 40mm Presta valve
FRONT TYRE // Butcher, GRID casing, Gripton compound, 2Bliss Ready, 27.5 x 2.8"
REAR TYRE // Butcher, GRID casing, Gripton compound, 2Bliss Ready, 27.5 x 2.8"
CRANKSET // Custom alloy crankarms
CHAINRINGS // Forged steel, 32T
SHIFT LEVERS // SRAM GX, one-click shift-lever
REAR DERAILLEUR // SRAM GX, long cage, 11-speed
CASSETTE // SRAM PG-1130, 11-speed, 11-42t
CHAIN // KMC X11ET, 11-speed w/ Missing Link™
FRONT BRAKE // SRAM Guide RE, hydraulic disc, 200mm
REAR BRAKE // SRAM Guide RE, hydraulic disc, 200mm
HANDLEBARS // Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 27mm rise, 780mm width
GRIPS // Specialized Sip Grip, half-waffle, XS/S: regular thickness, M/XL: XL thickness
STEM // Specialized Trail, 3D forged alloy, 4-bolt, 6-degree rise
SADDLE // Body Geometry Henge Comp, hollow Cr-Mo rails, 143mm
SEATPOST // Command Post IRcc, 12-position micro-height adjustable, alien head design, bottom mount cable routing, remote SRL lever, 30.9mm, S: 100mm, M/L/XL: 125mm of travel
SEAT BINDER // Alloy, 34.9mm
MOTOR // Specialized 1.3, custom Rx Trail-tuned motor, 250W Nominal
UI/REMOTE // Trail Handlebar Remote, motor mode switch & walk-assist
BATTERY // Specialized M1-504, integrated Trail Display, ANT+/Bluetooth® module, 504Wh, Mission Control App connectivity
CHARGER // Custom charger, 42V4A with Rosenberger plug
WIRING HARNESS // Custom Specialized wiring harness
PEDALS // Specialized Platform, Cr-Mo axle
