FRAME Specialized M5 Premium Aluminum, Trail HT Geometry, integrated down tube battery, enclosed internal cable and Command Post IR routing, 148mm spacing
FORK RockShox Recon Silver RL 29/27.5+, 15x110mm Maxle Lite thru-axle, Solo Air spring, adjustable rebound and lockout, 110/120mm of travel (size specific)
FRONT HUB Specialized disc, alloy, sealed cartridge bearings, 110x15mm thru-axle, 24h
REAR HUB Specialized disc, alloy, sealed cartridge bearings, 12x148mm thru-axle, 28h
SPOKES Stainless, 14g, black
RIMS Specialized 29, alloy disc, 23mm inner width, 24/28h
INNER TUBES 29x1.75/2.4", 40mm Presta valve
FRONT TYRE Ground Control, Control casing, 29x2.3", 60TPI, Aramid folding bead, 2Bliss Ready
REAR TYRE Fast Trak, Control casing, 29x2.2", 60TPI, Aramid folding bead, 2Bliss Ready
CRANKSET Custom alloy crankarms
CHAINRINGS 32T
BOTTOM BRACKET Integrated in motor
SHIFT LEVERS Shimano Deore, RapidFire Plus, 10-speed
REAR DERAILLEUR Shimano SLX, Shadow Plus, SGS cage, 10-speed
CASSETTE Sunrace, 10-speed, 11-40t
CHAIN SRAM PC1031, 11-speed w/PowerLink
FRONT BRAKE Shimano Deore BL-M506, hydraulic disc, resin pad, 200mm rotor
REAR BRAKE Shimano Deore BL-M506, hydraulic disc, resin pad, 180mm rotor
HANDLEBARS Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 27mm rise, 750mm width
GRIPS Specialized Body Geometry XCT Men's, lock-on
STEM Specialized, 3D-forged alloy, 4-bolt, 6-degree rise, 31.8mm clamp
SADDLE Body Geometry mountain, steel rails, 143mm
SEATPOST Alloy, 2-bolt clamp, 12.5mm offset, 30.9mm, anti-corrosion hardware
SEAT BINDER Alloy, 31.8mm
MOTOR Custom & exclusive for Specialized, Trail tuned, 250 W
UI/REMOTE Integrated Trail display, 10-LED battery display, Mission Control iOS/Android App
BATTERY Custom LEVO battery, 460Wh, 40x3.2Ah, ANT+/Bluetooth connectivity, IP 67
CHARGER Custom charger, 42V4A w/Rosenberger plug
WIRING HARNESS Custom harness w/ Rosenberger plug
PEDALS Alloy platform
As with any product, specification is subject to change without prior notification. You are advised to confirm current specification before buying.
