FRAME // A1 alloy, Sport XC 29 Geometry, zero-stack head tube, internal cable routing, 135x9mm forged dropouts, chainstay-mounted disc brake, replaceable alloy derailleur hanger
FORK // SR Suntour XCM w/ MCD 29, coil spring, custom Multi-Circuit damping, QR, 80/90/100mm travel (size-specific), 46mm offset
FRONT HUB // Shimano Center Lock, disc, 100x9mm QR, 32h
REAR HUB // Shimano Center Lock, disc, 135x9mm QR, 32h
SPOKES // Stainless, 14g
RIMS // Stout XC 25 29, alloy, disc only, double-wall, 25mm internal width, 32h
INNER TUBES // Presta, 40mm valve
FRONT TYRE // Ground Control Sport, Flak Jacket flat protection, wire bead, 29x2.3"
REAR TYRE // Ground Control Sport, Flak Jacket flat protection, wire bead, 29x2.1"
CRANKSET // Stout, forged alloy, 3x9
CHAINRINGS // 44/32/22T
BOTTOM BRACKET // Square taper, 73mm, internal bearings
SHIFT LEVERS // Shimano Acera 3x9
FRONT DERAILLEUR // Shimano Altus FD-M371, 34.9mm clamp, down-swing
REAR DERAILLEUR // Shimano Acera, 9-speed
CASSETTE // Sunrace, 9-speed, 11-34t
CHAIN // KMC X9EPT, 9-speed, anti-corrosion coating w/ reusable Missing Link™
FRONT BRAKE // Shimano BR-M315, hydraulic disc, resin pads, 180/160mm rotor
REAR BRAKE // Shimano BR-M315, hydraulic disc, resin pads, 160mm rotor
HANDLEBARS // Stout double-butted alloy, 10mm rise, 10-degree backsweep, 4-degree upsweep, 720mm width, 31.8mm
GRIPS // Specialized MTB Grip, lock-on
STEM // Stout 3D-forged alloy, 31.8mm, 6-degree rise
SADDLE // Henge Sport, steel rails, 143mm
SEATPOST // Alloy, 12mm offset, 2-bolt clamp, 30.9mm
SEAT BINDER // Alloy, QR clamp, 34.9mm
PEDALS // Specialized Dirt
