As this is not a brand new bike, it may not feature the full original technical specification and is subject to change.
FRAME // S-Works FACT 12m, XC Geometry, Rider-First Engineeredâ„¢, threaded BB, 12x148mm rear spacing, internal cable routing, 100mm of travel
FORK // FOX Factory Step-Cast 34, Fit4 damper, Kashima, Boostâ„¢, 44mm offset, 120mm of travel
REAR SHOCK // Custom RockShox Micro Brain shock w/ Spike Valve, AUTOSAG, 51x257mm
FRONT HUB // Roval Control SL, sealed cartridge bearings, 15mm thru-axle, 110mm spacing, 24h
REAR HUB // Roval Control SL, DT Swiss Star Ratchet, 54t engagement, DT microspline, 12mm thru-axle, 148mm spacing, 28h
SPOKES // DT Swiss Industry
RIMS // Roval Control SL, hookless carbon, 25mm internal width, tubeless-ready, hand-built
INNER TUBES // Presta, 60mm valve
FRONT TYRE // Ground Control, GRIPTON® compound, 60 TPI, 2Bliss Ready, 29x2.3"
REAR TYRE // Fast Trak, GRID casing, GRIPTON® compound, 60 TPI, 2Bliss Ready, 29x2.3"
CRANKSET // Shimano XTR M9100, Hollowtech-2
CHAINRINGS // 32T
BOTTOM BRACKET // Shimano BB93
SHIFT LEVERS // Shimano XTR M9100, 12-speed
REAR DERAILLEUR // Shimano XTR M9100, 12-speed, Shadow Plus
CASSETTE // Shimano XTR M9100, 12-speed, 10-51t
CHAIN // Shimano XTR M9100, 12-speed, quick-link
FRONT BRAKE // Shimano XTR Race M9100
REAR BRAKE // Shimano XTR Race M9100
HANDLEBARS // S-Works Carbon Mini Rise, 6-degree upsweep, 8-degree backsweep, 10mm rise, 750mm, 31.8mm
GRIPS // Specialized Sip Grip, half-waffle, S/M: regular thickness, L/XL: XL thickness
STEM // S-Works SL
SADDLE // Body Geometry Phenom Pro, carbon fiber rails, carbon fiber base, 143mm
SEATPOST // FOX Factory Transfer, Kashima, Shimano Ispec-EV lever (S: 100mm, M-XL: 125mm)
SEAT BINDER // Alloy, 34.9mm, titanium bolt
PEDALS // Specialized Dirt
As with any product, specification is subject to change without prior notification. You are advised to confirm current specification before buying.
*Please note that due to production issues with the new Shimano XTR cranks, only our initial delivery of S-Works Epic EVO bikes in LG and XL were shipped with the Shimano XTR cranks. SM and MD S-Works Epic EVO bikes (and any future stock) will be supplied with a RaceFace Next SL carbon crank.
