frame
M5 alloy, Style-Specific DH Geometry, horst pivot flip chip for 27.5 or 29 rear wheel, BSA threaded BB, full internal cable routing with option for full external brake, 148mm rear spacing, sealed cartridge bearing pivots, replaceable derailleur hanger, 200mm of travel
rear shock
Ohlins TTX 22 M Coil, external rebound adjust, external high and low speed compression adjustment, Trunnion mount, 225x75
fork
Ohlins DH38 M.1 29, TTX Twin Tube Damping, external low speed rebound adjust, external high and low speed compression adjustment, 20x110mm, 58mm offset, 200mm of travel
stem
Roval Traverse SL Carbon, riser bar, 6-degree upsweep, 8-degree backsweep, 30mm rise, 800mm, 35.0mm
handlebars
Roval Traverse SL Carbon, riser bar, 6-degree upsweep, 8-degree backsweep, 30mm rise, 800mm, 35.0mm
grips
Deity, Knuckleduster, Black
saddle
Body Geometry Henge DH, hollow titanium rails, 130mm
seatpost
Thomson, alloy, straight, 12-degree clamp
front brake
Magura MT7, 4-piston caliper, hydraulic disc, 200mm
rear brake
Magura MT7, 4-piston caliper, hydraulic disc, 200mm
rear derailleur
SRAM X01 DH, 7-speed, trigger
shift levers
SRAM X01 DH, trigger, 7-speed
cassette
SRAM X01 DH, 7-speed, 10-24t
chain
Sram PC1130 w/ Powerlink, 11-speed
crankset
SRAM X01 DH, DUB, carbon, Direct mount ring, 165mm
chainrings
34T
bottom bracket
SRAM DUB, 83mm
rims
Roval 29" Alloy DH, 28mm internal width, 28h, tubeless ready
front hub
Alloy, sealed cartridge bearings, 20x110mm, 28h
rear hub
DT Swiss 350, SRAM XD freehub, 6-bolt disc, high-low flange, sealed cartridge bearings, 12x148mm spacing, 28h
spokes
DT Swiss Competition, stainless steel, 14g
front tyre
Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"
rear tyre
Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 27.5x2.3"
inner tubes
Standard, Presta Valve
seat binder
Alloy, 34.9mm
As with any product, specification is subject to change without prior notification. You are advised to confirm current specification before buying. Please note that this bike does not come with pedals.
