frame
FACT 11m carbon chassis and rear-end, asymmetrical design, 29 Trail Geometry, SWAT™ Door integration, flip chip Head Tube/Bottom Bracket adjustment, threaded BB, fully enclosed internal cable routing, 12x148mm UDH compatible rear spacing, sealed cartridge bearing pivots, 130mm of travel
rear shock
FOX FLOAT DPS Factory, Rx Trail Tune, EVOL Air sleeve, Kashima Coat, 3-position adjustment w/ Open Mode Adjustment, 190x45mm
fork
FOX FLOAT 34 Factory, GRIP2 damper, Kashima Coating, 15x110mm, 44mm offset, 140mm of travel
stem
Deity, 35.0mm
handlebars
Roval Traverse SL Carbon, riser bar, 6-degree upsweep, 8-degree backsweep, 30mm rise, 780mm, 35.0mm
grips
Deity Lockjaw
saddle
Bridge, 155/143mm, Hollow Ti-rails
seatpost
Bike Yoke, Revive Max, 34.9 (S1:120mm, S2-S3:150mm, S4-S5: 185mm, S6:213mm)
front brake
SRAM Code Silver Stealth, 4-piston caliper, hydraulic disc, 200mm HS2 Rotor
rear brake
SRAM Code Silver Stealth, 4-piston caliper, hydraulic disc, 180mm HS2 Rotor
rear derailleur
SRAM X0 Eagle Transmission Derailleur
shift levers
SRAM AXS POD Controller
cassette
SRAM X0 Eagle Transmission Cassette, 12spd, 10-52t
chain
SRAM X0
crankset
SRAM X0 Eagle Crankset, Alloy, Integrated Guard, 55mm Chainline, S1:165mm, S2-S5: 170mm, S6: 175mm
chainrings
32T
bottom bracket
SRAM DUB, BSA 73mm Wide, Threaded
rims
Roval Traverse Carbon 29, hookless carbon, 30mm inner width, hand-built, 2Bliss Ready
front hub
DT Swiss 350, sealed cartridge bearings, 15x110mm spacing, 28h
rear hub
DT Swiss 350, Star Ratchet, 36t engagement, SRAM XD driver body, 12mm thru-axle, 148mm spacing, 28h
spokes
DT Competition Race
front tyre
Butcher, GRID casing, GRIPTON® T9 compound, 29x2.3"
rear tyre
Purgatory, GRID casing, GRIPTON® T7 compound, 29x2.3"
inner tubes
Standard, Presta valve
seat binder
Alloy, 38.6mm
weight
13.15kg (28 lb, 15.9 oz)
weight size
S4
As with any product, specification is subject to change without prior notification. You are advised to confirm current specification before buying. Please note that this bike does not come with pedals.
