FRAME // M5 alloy, Trail Geometry, PF30 BB, internal cable routing, ManFu link, 12x148mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 135mm of travel
FORK // RockShox Revelation RL 29/27.5+, Solo Air spring, lockout and rebound adjust, 15x110mm Maxle Lite thru-axle, 51mm offset, 150mm travel
REAR SHOCK // RockShox Monarch RT, Rx Trail Tune, AUTOSAG, rebound and 2-position compression adjust, 197x48mm
FRONT HUB // Specialized disc, alloy, sealed cartridge bearings,15x110mm thru-axle, 24h
REAR HUB // Specialized disc, alloy, sealed cartridge bearings, 12x148mm thru-axle, 28h
SPOKES // DT Swiss Industry, stainless, 3x, 2.0"
RIMS // Roval Traverse 650b, hookless alloy, 29mm inner width, 24/28h, tubeless ready
INNER TUBES // Standard, Presta valve
FRONT TYRE // Purgatory, GRID casing, 650bx3.0", 60TPI, Aramid folding bead, 2Bliss Ready
REAR TYRE // Purgatory, GRID casing, 650bx3.0", 60TPI, Aramid folding bead, 2Bliss Ready
CRANKSET // RaceFace Aeffect, 6000-series alloy, 24mm spindle, 52mm chainline, 28T
SHIFT LEVERS // SRAM GX, 11-speed, trigger
REAR DERAILLEUR // SRAM GX, long cage, 11-speed
CASSETTE // SRAM XG-1150, 11-speed, 10-42t
CHAIN // SRAM PC-1110, 11-speed w/PowerLink
FRONT BRAKE // SRAM Guide R, hydraulic disc, organic pads, Guide S4 4-piston caliper, 200/180mm rotor
REAR BRAKE // SRAM Guide R, hydraulic disc, organic pads, Guide S4 4-piston caliper, 180/160mm rotor
HANDLEBARS // Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 27mm rise, 750mm width
GRIPS // Specialized Sip Grip, half-waffle, S/M: regular thickness, L/XL: XL thickness
STEM // Specialized Trail, 3D forged alloy, 4-bolt, 6-degree rise
SADDLE // Body Geometry Henge Comp, hollow Cr-Mo rails, 143mm
SEATPOST // Command Post IRcc, 12 position micro-height adjustable, alien head design, bottom mount cable routing, remote SRL lever, 30.9mm, S: 100mm, M/L/XL: 125mm travel
SEAT BINDER // Alloy, 34.9mm
PEDALS // Resin Test Ride w/toe clips
