SRAM Disc Brake G2 Reach E-MTB Guide Aluminium Lever Cde 4Piston Caliper Front 950mm Hose A2 - Rotor/Bracket Sold Separately
SRAM Disc Brake G2 Reach E-MTB Guide Aluminium Lever Cde 4Piston Caliper Front 950mm Hose A2 - Rotor/Bracket Sold Separately
SRAM

SRAM Disc Brake G2 RE Guide Lever Code 4Piston Caliper Front 950mm Hose

£140.00
Pre-Order

With Pre-Order, you can purchase the latest items added to our store in advance of them arriving with us.

Your Pre-Order is prioritised (at no additional charge); meaning that as soon as the product arrives with us, we can wrap it straight back up; ready for collection via Click & Collect or despatch to you — it often never even hits the stock room shelves!

Pre-Launch

With Pre-Launch, the date when we expect to receive the product ourselves is still a little too hazy to be confident in accepting Pre-Orders.

So, instead, you can submit your email address against the item you are interested in and we will email you as soon as stock arrives on the system.

Estimated Delivery & Collection Dates

Estimated Delivery & Collection Dates are given on Pre-Order and Pre-Launch products. They are for indication purposes only and can change at any time without notice.

The dates we provide are based on indications given by our suppliers. Whenever we get updated information from our suppliers we will endeavour to update the Estimated Delivery & Collection Dates provided on product pages.

We estimate this will be ready for despatch to you or collection via Click & Collect on Undetermined

SRAM Disc Brake G2 RE Guide Lever Code 4Piston Caliper Front 950mm Hose

Brand:SRAM

Code:DBS8209000

SRAM Disc Brake G2 Reach E-MTB Guide Aluminium Lever Cde 4Piston Caliper Front 950mm Hose A2 - Gloss Black

Rotor/Bracket Sold Separately

Built for the demands of modern electric mountain bikes, the SRAM G2 RE Front Disc Brake delivers powerful, consistent braking performance for aggressive trail riding. Featuring a durable aluminium G2 R lever and a high-performance 4-piston caliper inspired by SRAM’s gravity-focused Code brakes, the G2 RE is engineered to handle the increased speeds and weight of E-MTBs. With 950mm hose length and sleek gloss black finish, this front brake offers exceptional modulation and stopping power across all terrain, uphill, downhill, and everything in between.

Technical Information
  • Application (DB):
    MTB
  • Brake type:
    Hydraulic
  • Blade material:
    Aluminum - Stamped
  • Contact adjust:
    No
  • Colour (DB):
    Gloss Black
  • Rec MMX clamp (not included):
    Stl(glossblk)bolt,blk clp
  • Orientation:
    Front
  • Pad type (Disc):
    Steel-backed metal sintered
  • Bracket (Disc Brake):
    Direct mount DIR
  • Hose length (mm):
    950mm
  • Rear banjo option:
    n/a
  • Rotor (AM only):
    n/a
  • Connectamajig:
    n/a
  • Reach adjust:
    Tool-free
  • Rec discrete clamp (not included):
    Hinge - Steel - gloss black
  • Pad adjust:
    n/a
  • Pistons:
    4
  • Piston material:
    Phenolic Plastic
  • Hose routing angle:
    Adjustable banjo
  • Caliper body material:
    Forged Aluminum
  • Caliper hardware:
    Steel
  • Caliper construction:
    2-piece
  • Hydraulic fluid:
    DOT 5.1
  • Lever pivot:
    Bushing
  • Lever body material:
    Forged Aluminum
  • Rotor type recommended:
    1-piece HS2
  • Clamp Included (DB):
    Yes – MMX Clamp
  • Caliper Bleed Port:
    Threaded
As with any product, specification is subject to change without prior notification. You are advised to confirm current specification before buying.
