Rims:
Material: Maxtal
Height: 26mm, asymmetrical
Joint: SUP
Drilling: Fore
Disc brake specific profile
Weight reduction: ISM 4D
Valve hole diameter: 6.5 mm
Tyre: UST Tubeless and tubetype
Internal width: 19 mm
ETRTO size: 622x19C
Spokes:
Material: steel
Shape: straight pull, bladed
Nipples: Fore integrated aluminum
Count: 24 front and rear
Lacing: front crossed 2, rear Isopulse
Hubs:
Front and rear bodies: aluminum
Axle material: aluminum
Sealed cartridge bearings
Freewheel: Instant Drive 360
Front: Quick release, 12x100 and 15x100 compatible
Rear: Quick Release, 12x142 and 12x135 compatible
Tyre:
Yksion Elite Guard or Yksion Elite Allroad
UST Ready (Yksion Elite Allroad only)
Front and Rear Tread: Single Compound
Casing: 120 TPI
Breaker: Polyamide, from bead to bead
Dimensions: 28-622 (700x28c) or 30-622 (700x30C)
Versions:
Color: Black only
Disc standard : 6 Bolts or Center Lock(R)
Compatibility:
Freewheel: Shimano/Sram, convertible to Campagnolo and XD-R with optional driver bodies
Front axle: convertible from 12mm thru axle to quick release or 15mm thru axle with optional adapters
Rear axle: 12mm thru axle, convertible to Quick Release with optional adapters (not available in Germany)
Provided with:
Front 12 mm adapters (Supplied with purchase of pair or front wheel)
Rear 12x142mm adapters for Instant Drive 360 (Supplied with purchase of pair or rear wheel)
Specific disc bolts
Multifunction adjustment wrench
User guide
Rim profile: Ksyrium Pro Allroad Disc
Intended use:
ASTM CATEGORY 2 : road and offroad with jumps less than 15cm
For a longer longevity of the wheel, Mavic recommends that the total weight supported by the wheels don't exceed 120kg, bike included
Recommended tyre sizes: 28 to 42 mm
Max. Pressure: 28mm 7.7 bars - 110 PSI / 30mm 5.8 bars - 85 PSI
Weight:
Weight Front 780
Weight Pair 1690
Weight Rear 910
Weight Tyre 700x28 245
Weight Tyre 700x30 330
